BLT-165 Silent Hydraulic Breaker
Ultra Heavy-Duty Hydraulic Hammer for 35–45 Ton Excavators (77,000–99,200 lb)
The BLT-165 Silent Type Hydraulic Breaker is designed for extreme-duty demolition, quarry, mining, and large infrastructure projects. With its fully enclosed sound-suppressed housing, it delivers maximum impact power while significantly reducing noise and vibration during operation.
Built for high productivity in the toughest working conditions, the BLT-165 is ideal for large-scale rock breaking, reinforced concrete demolition, and heavy civil engineering applications.
Key Features
- Fully enclosed sound-suppressed (silent type) design
- Extremely high impact energy for large-scale demolition
- Reinforced heavy-duty body structure for long service life
- Reduced vibration for better excavator protection
- Stable performance under continuous extreme load
- Optimized hydraulic efficiency for large machines
- Easy maintenance and service access
Technical Specifications
| Specification | Metric | Imperial |
|---|---|---|
| Model | BLT-165 | — |
| Breaker Type | Silent / Sound Suppressed | — |
| Suitable Excavator | 35–45 Ton | 77,000–99,200 lb |
| Operating Weight | 3450 kg | 7,606 lb |
| Total Length | 3510 mm | 11.5 ft |
| Tool Diameter | 165 mm | 6.5 in |
| Chisel Length | 1500 mm | 4.9 ft |
| Oil Flow | 210–270 L/min | 55–71 GPM |
| Working Pressure | 210–230 bar | 3,045–3,335 psi |
| Relief Pressure | 250–260 bar | 3,625–3,770 psi |
| Impact Rate | 180–280 bpm | 180–280 bpm |
| Hose Diameter | 1.5 inch | 38 mm |
| Nitrogen (Back Head) | 18–22 bar | 261–319 psi |
| Nitrogen (Accumulator) | 60–65 bar | 870–943 psi |
Compatible Excavators
Designed for 35–45 ton excavators, including:
- Caterpillar 336 / 340 / 345
- Komatsu PC350 / PC360 / PC400
- Volvo EC380 / EC400 / EC480
- Hitachi ZX350 / ZX380 / ZX400
- Hyundai R380 / R420
- Doosan DX380 / DX420
- Kobelco SK380 / SK430
- SANY SY365 / SY385 / SY420
- Liugong 936 / 950
Applications
- Heavy rock breaking
- Large-scale demolition
- Quarry and mining operations
- Bridge and highway construction
- Foundation excavation
- Industrial site preparation
- Tunnel and infrastructure projects
Built for Extreme Workloads
The BLT-165 delivers maximum hydraulic impact power for the most demanding applications. Its reinforced structure and optimized hydraulic system ensure durability, efficiency, and stable performance on large excavators operating in extreme conditions.
