BLTB 70 hydraulic hammer for 9,900 – 13,200 lbs excavator

BLTB-100A Hydraulic Breaker for Excavators

Heavy-Duty Performance for 10–14 Ton Machines

The BLTB-100A Hydraulic Breaker is built for contractors who need reliable performance in demolition, trenching, and rock breaking. Designed for 10–14 ton excavators, it delivers consistent impact power with low maintenance requirements.

🔧 Key Features

• High productivity in tough job site conditions
• Durable construction for long service life
• Easy setup and operation
• Efficient hydraulic system for stable performance
• Low maintenance design

⚙️ Technical Specifications

• Working Weight: 1020 kg (2,249 lbs)
• Total Length: 2081 mm (82 in)
• Carrier (Excavator): 10 – 14 ton (22,000 – 30,800 lbs)
• Working Oil Flow: 80 – 110 L/min (21 – 29 GPM)
• Operating Pressure: 150 – 170 bar (2,175 – 2,465 psi)
• Set Pressure (Excavator): 210 bar (3,045 psi)
• Impact Rate: 350 – 700 bpm
• Chisel Diameter: 100 mm (3.94 in)
• Chisel Length: 1000 mm (39.4 in)
• Hose Diameter: 3/4 inch
• Nitrogen Pressure (Back Head): 14 – 17 bar (203 – 247 psi)
• Nitrogen Pressure (Accumulator): 55 – 60 bar (798 – 870 psi)
• Noise Level: 85 dB

⚙️ Applications

• Concrete demolition
• Roadwork & asphalt breaking
• Trenching & utility work
• Rock breaking
• Construction site preparation

💰 Built for Productivity

The BLTB-100A is designed to deliver:

• Consistent удар without power loss
• Reduced downtime
• Reliable performance under load
